Technical data
Advantages
- Constant capacity, directly proportional to the rotation speed and quite independent of the pressure.
- Smooth flow, without pulsations or pressure peaks which could cause vibrations in the pipework.
- Reversibility. By inverting the direction of rotation the flow of liquid is reversed. Full performance is available in either direction of flow. Reversible flow up to 3 bar as standard, up to 12 bar with hydraulic balance on request.
- Self-priming. The high vacuum created by the pump permits rapid self-priming at the maximum height made possible by the physical characteristics of the pumped liquid (temperature, vapour pressure, viscosity, etc.). Large cross section between stator and casing, with smooth design, to improve the priming of the product.
- Rubber sleeves designed with special geometry to increase the durability. Reliable operation even in presence of sharp solids in the medium.
- Pump coupled to the motor with high resistance pin in order to ensure the complete reversibility.
- Transmission shaft with universal pin joint, bushing guide and transmission guide to enable long endurance and reliability. Bushings made to minimize the wear of the pin, avoiding the replacement of the transmission shaft and minimizing the costs of repair and maintenance downtime.
- Easy and cheap maintenance. Few components subject to wear and with compact size.
Applications
To ensure correct pump operation, it is crucial to pick the right product with respect to the application and the chemical-physical characteristics of the fluid being treated.
Sewage plants
dirty waste water, sludge.
Food & Beverage
grapes, grape paste, wine, fruit juice pulp, liquors, beer, fruit paste, tomatoes, pulp fruit, vegetable, milk products, flour, dough, chocolate, creams
Paper Industry
cellulose, glue, pulps, patinas, starch.
Paints and inks
solvent, ink paste, pigment, paint.
Cosmetic Industry
soap, cream, tooth-paste, shampoo, detergent.
Chemicals
resins, reagents, acids, biodiesel.
Resins
Resins are synthetic materials used in a wide range of applications, from the production of construction materials to paints, from adhesives and packaging products to rubbers.
Marine
oil sludge, bilge water, sea water.
